UNISPORT Portable Padel Court with Modular Foundation
We use cookies to improve your online experience. By continuing browsing this website, we assume you agree our use of cookies.

UNI - Modular Foundation Padel Court

Item No.: 00418
Modular portable padel court requires no civil work. Sturdy durable structure, easy to install and move. Eco-friendly design protects ground, certified and customizable.
Description Technical Specifications FAQ Review
Description

Core Description

The portable foundation system for padel courts, introduced by UNISPORT, is a revolutionary solution designed to overcome the critical challenges of modern court installation:
Eliminate Dependence on Traditional Foundations: It removes the need for permanent concrete foundations, making rapid construction possible even in environments where building permits are unavailable or ground excavation is unfeasible.
All-Terrain Compatibility: Utilizing a precision-engineered support structure, the court is securely suspended above grass, sand, or any uneven terrain.

Key Features and Advantages

Zero Civil Engineering Costs: Eliminates the need for expensive ground excavation and concrete pouring, streamlining the project approval process and significantly shortening the construction cycle.
Exceptional Flexibility: Fully demountable and reusable, supporting the complete relocation of assets to a new site to safeguard your investment.
Professional Athletic Feel: Featuring the "Soft Touch" effect, which utilizes the slight elastic deflection of the metal framework to provide shock absorption, protecting athletes' ankles and knees.
Sustainability: Constructed with recyclable components and eco-friendly materials, ensuring zero damage to the existing ground surface.

Authoritative Certifications

EU RoHS Environmental Testing: Passed 2011/65/EU and EU 2015/863 tests, ensuring the absence of hazardous substances like lead, mercury, and cadmium.
EU CE Construction Materials Certification: Complies with EN 14566:2008+A1:2009 standards (Certificate No: EU 305/2011).
Technical Specifications

Technical Specifications
1. Main Framework

• Side Beams: 100×200×3.0mm rectangular steel tubes.
Reinforcements: 14mm thick connecting plates and 8mm hot-dip galvanized steel plates.
Surface Treatment: Dual-layer anti-corrosion process (Hot-Dip Galvanizing + Powder Coating).

2. Load-Bearing Base

Frame: Welded 40×40mm steel tubing.
Panels: 18mm thick high-density, fireproof, and waterproof specialty high-strength boards.
Load Capacity: Each support leg can bear up to 2,765 kg.

3. Adjustment and Hardware

Adjustment Range: 180mm height-adjustable support components.

Fasteners: Grade 8.8 high-strength bolts and 304 stainless steel anti-theft hardware.

Application Scenarios

• Environments where traditional building permits are difficult to obtain.

Sites where permanent groundworks or excavation are restricted.

Installation on grass, sand, or any irregular terrain.

Projects requiring temporary or relocatable sports facilities.

FAQ

FAQ
1. Is it stable enough for professional matches?

Yes. The 6-ton integrated steel framework ensures maximum stability and a professional playing experience identical to concrete-based courts.
2. Can I install it on rooftops or existing parking lots?
Absolutely. Its point-load distribution is much lighter and safer for rooftops than concrete slabs. We can provide load reports for your building engineer.
3.  Does this court require a permanent building permit?
Usually no. Since it is classified as a "temporary/movable structure," it often bypasses the complex permit process required for permanent construction.
4. How do you handle uneven ground or slopes?
We use adjustable pedestals that can level the court up to 180mm, ensuring a perfectly flat surface even on sloped floors.
5. Is it easy to relocate if I move my club?
Yes. The system is 100% bolt-based and can be fully disassembled in 2 days without any damage to the site.
6. What is the lifespan in outdoor environments?
 Over 15 years. All steel parts are hot-dip galvanized and powder-coated to resist corrosion in high-humidity or coastal areas.
7.  Does it have good drainage?
Yes. The elevated design allows water to drain naturally through the turf, preventing water pooling and mold growth.
