Description

About UNISPORT Padel Court

UNISPORT padel courts are designed and manufactured strictly according to FIP standards. The entire series uses high-quality hot-dip galvanized Q235 steel as the main material, combined with polyester powder coating/electrostatic powder coating processes. They are wind and rain resistant, corrosion resistant, and easy to maintain. The walls and roofs use industry-leading materials, ensuring both structural stability and user experience.

We offer a full range of padel courts, including panoramic, C-shaped panoramic, classic, covered, portable, and singles courts. We support standard-sized floor installations and personalized customization, providing integrated facilities and installation services.

Standard Dimensions of Padel Courts

Padel courts have rapidly gained popularity worldwide, not only in the United States, South America, and Europe, but also in other regions.

Double Standard: 20 meters long x 10 meters wide, total area 200 square meters. At least 0.5 meters of operating space must be reserved around the perimeter of the court.

Singles Standard: 20 meters long x 6 meters wide, suitable for individual training/small recreational courts.

General Configuration:

• Rectangular layout. Side and back walls are typically 3 meters high, and the front wall (net edge) is 2 meters high.

• 12mm tempered glass has four times the impact resistance of ordinary glass and a light transmittance of 87%, suitable for standard competition and recreational padel courts.

• LED lighting system power 200W, lifespan ≥ 50,000 hours.

Space Reserved for Padel Court Construction

When planning a project, it is essential to ensure that sufficient space is reserved around the padel court. To ensure player safety, professional padel courts should have a minimum perimeter width of 0.5 meters (1 foot 8 inches). Recreational padel courts should follow the same recommendation. For venues with multiple padel courts, the required spacing between courts should be considered.

Dimensions

Different padel courts Dimensions

Super Panoramic Padel Court
• Dimensions: 20×10 m
• Uprights: 100×100×3mm, 3m high
• Frame and Light Posts: 100×50×3mm, 3m high
• Key Advantages: Panoramic view design, tournament-level visual experience; hot-dip galvanized steel main frame, deformation-resistant and strong load-bearing capacity; high-specification netting and wall construction, maximizing durability.
• Suitable Scenarios: Professional plywood tennis tournament venues, high-end commercial sports clubs, etc.

C-Type Panoramic Padel Court
• Dimensions: 20×10 m
• Corner Posts: 80×80×3mm, 3m high
• Frame Posts/Gate Frame Posts and Light Posts: 80×60×3mm, 3m high
• Advantages: C-type panoramic design for a wide field of vision; lightweight steel structure for easy installation and structural stability; cost-effective specifications balancing quality and cost; adaptable to various scenarios for rapid deployment.
• Suitable Scenarios: Community sports centers, small and medium-sized commercial clubs, corporate leisure and sports areas

Classic Padel Court
• Dimensions: 20×10 m
• Corner Posts: 100×100×3 mm, 3 meters high
• Frame Posts and Light Posts: 100×50×3 mm, 3 meters high
• Advantages: Classic and simple design, high site utilization; standardized steel structure layout, convenient maintenance; materials and workmanship meet competition-level standards, ensuring a superior sports experience;
• Applicable Scenarios: Public leisure sports venues, community fitness areas, outdoor sports parks, small training bases

Classic Roofed Padel Court
• Dimensions: 20×10 m
• Dimensions: 13.5×22 m
• Side height: 6 m
• Arch height: 8.5 m
• Post: 100×100×4 mm
• Canopy: PVC coated banner
• Advantages: Full-canopy design for rain and sun protection, enabling all-weather sports; high-specification columns and roof frame for strong wind and pressure resistance;
• Suitable scenarios: Commercial clubs, professional training venues, high-end community sports centers, and indoor/outdoor sports projects in rainy/sunny areas.

Panoramic Roofed Padel Court
Sizes: 20×10 m
Size:13.5×22 m
Side Height: 6 m
Arch high: 8.5 m
Post : 100×100×4 mm
• Canopy: PVC coated banner
• Advantages: PVC canopies are waterproof, sun-proof, durable, and suitable for various venue styles.;
• Suitable scenarios: Commercial clubs, professional training venues, high-end community sports centers, and indoor/outdoor sports projects in rainy/sunny areas.

Portable Padel Court
• Sizes: 20×10 m
• Column support frame: 1672×220mm
• Installation vertical distance: 1800mm
• Bottom parallel bracket length: 763mm
• Advantages: Modular design for easy installation and transport; reusable, suitable for temporary events or activities; stable steel frame ensures safety during sports activities; no complex foundation required for quick deployment.
• Applicable Scenarios: Temporary tennis tournaments, sports exhibitions, outdoor pop-up sports areas, temporary corporate sports activities.

Classic Single Padel Court
• Sizes: 20×6 m
• Corner Column: 100×100×3 mm, 3 meters high
• Frame Column & Light Post:100×50×3 mm, 3 meters high
• Suitable scenarios: Individual training / Small recreational spaces

Panoramic Single Padel Court
• Sizes: 20×6 m
• Corner Column: 80×80×3mm, 3 meters high
• Frame Column & Door Frame Post & Light Post: 80×60×3mm, 3 meters high

Custom Electric Tent Padel Court
• Main carrier: 100×150×5 mm
• Interconnect structures: 60 ×60×3 mm
• Roof trusses: Ø89/4 mm
• Modular bolted system Height: 8 - 8 m
• Material: High quality hot galvanized Q235 steel |Polyester powder coating treatment | Electrostatic Powder Coating
• Indoor Dimensions: 22×14 m

Stadium size contact us to customize

Other Areas

Dimensions of other areas of padel court

In other areas of padel court, the height of the net is very critical. The net is located in the center of the court, with a height of 88 cm in the center of the net and 92 cm on both sides. The height of the net directly affects the trajectory of the ball and the quality of the game, so it needs to be installed accurately to ensure fair and smooth play.

The serving area and the no-volley zone are important parts of the court. Each padel court has two serving areas, each with an area of 5×5 meters, which ensures the legality of serving and the fairness of the game. The no-volley zone in front of the net is 3 meters wide. Players cannot volley in this area, which has a profound impact on the offensive and defensive strategies in the game and is a key area that cannot be ignored in the game.

The side walls of the court are 3 meters (9.84 feet) high, the back wall is 4 meters (13.12 feet) high, and the side walls of the court are also 3 meters high. The walls are made of different materials and have different heights. Specifically, the 12 meters (39.37 feet) wall in the center of the court is made of plastic or metal mesh, while the remaining 4 meters of the side walls and 10 meters of the back wall are made of a mixture of glass and mesh. For the bottom of the side walls and the back wall, the glass is 3 meters (9.84 feet) high and the upper part is 1 meter (3.28 feet) of mesh; while for the rest of the side walls, there is 2 meters (6.56 feet) of glass at the bottom and 1 meter (3.28 feet) of glass at the top.

FAQ

Some questions you might want to know:
1. Do your padel courts meet international standards?

Our entire series of padel courts are designed and manufactured strictly according to the FIP (International Paddleboard Tennis Federation) standards. From court dimensions, net height, wall height to steel structure specifications, they all meet the requirements of professional sports and competitions, suitable for professional matches and daily operations.

2. What is the difference between the panoramic and classic padel courts?

The panoramic padel court (super panoramic/C-type) features a wide field of vision, with walls primarily composed of glass and net surfaces, providing an excellent visual experience, suitable for high-end commercial venues and competitions. The classic padel court focuses on net surfaces and walls, with a simple design, high space utilization, and higher cost-effectiveness, suitable for general recreation and basic training scenarios. Both courts meet standard sports requirements.

3. Does a portable padel court require a professional foundation?

Portable padel courts feature a modular, disassembly-and-assemble design, requiring no complex foundation; only a level surface is needed for installation. With professional team operation, assembly and disassembly can be completed quickly, the specific installation time depending on the site conditions. Temporary events/campaigns can be quickly set up and dismantled.

4. Do you support customized services for padel courts?

We support full-dimensional customization, including court size, material matching, wall style, and roof design. We can create a customized solution based on the customer's site conditions, usage scenario, and budget requirements.

5. Do you provide installation and after-sales service for padel courts?

We provide one-stop installation and after-sales support services, with a professional installation team supporting installation in domestic and overseas venues. We also provide after-sales services such as daily site maintenance guidance, parts replacement, and subsequent inspections, eliminating any concerns for our customers.
